Dornier 328
Dornier · D328
Dornier 328, a German regional turboprop. US Airways Express and several European regionals operated it.
A twin-engine turboprop in the small category that cruises at M0.50. Is vulnerable to wake turbulence from heavier types.
2x TurbopropSmallRECAT FFL310 ceilingILS capable
Performance
| Parameter | Value |
|---|---|
| Engines | 2 x Turboprop |
| Weight class | Small (S) |
| RECAT-EU category | F (Light) |
| Service ceiling | 31,000 ft (FL310) |
| Max climb rate | 2,000 fpm |
| Max descent rate | 1,500 fpm |
Speed envelope
| Parameter | Value |
|---|---|
| Minimum speed | 105 kts |
| Landing speed | 130 kts |
| Cruise speed | 340 kts (M0.50) |
| Maximum speed | 400 kts (M0.60) |
Runway requirements
Field lengths used in the simulation for takeoff/landing calculations.
| Parameter | Value |
|---|---|
| Takeoff field length | 6,744 ft (1.11 nm) |
| Landing field length | 6,137 ft (1.01 nm) |
Equipment
| Capability | Status |
|---|---|
| ILS approaches | Yes |
| Fix navigation | Yes |
| SRS category | 3 |
| LAHSO category | 7 |
